Industrial lighting Factor LED C5-M

Downloads

Specification

Factor Led C5-M (corrosion protection in harsh industrial and marine environments) is the latest generation of high-powered floodlight with impressive lumen output. It is characterised not only by very high luminous efficiency, but also by high IP66 sealing and IK09 impact resistance. These parameters were achieved thanks to the branded components used, the robust housing made of cast aluminium LM-6 (aluminium-silicon alloy) and the use of a passive lamp cooling system, which allows excess heat generation to be dissipated during lamp operation. In the C5-M version, the paint coating plays an even more important role. The Factor Led has the advantage of being very quick and easy to install. The lightweight steel arm is attached to the supporting structure (wall, column) and then the light modules are plugged in. On one bracket, the installer can plug in a lamp containing 1 to 4 such modules.

Application

Very good sealing and impact resistance parameters, the ability to operate at elevated temperatures - up to 45˚C as standard - and an extensive range of beam patterns predispose Factor Led lamps for use in difficult weather conditions. It can be used and performs excellently both inside industrial halls, warehouses, sports halls, logistics centres and outdoors - on sports pitches, airports, car parks, manoeuvring areas. It can also illuminate the facades of buildings and external architectural elements.

Options

Rated power of the luminaire [W]	Luminous flux [lm]	Beam angle [°]	Diffuser material	Version	Colour rendering index	DIMM DALI	Dimensions (H/W/T/S) [mm]	Index
101	16000	90	PC	1 module	>80	-	191/425/217	682001
120	16600	120	tempered glass	1 module	>70	-	191/425/217	682018
120	17000	RM7	tempered glass	1 module	>70	-	191/425/217	682025
120	17200	RM3	tempered glass	1 module	>70	-	191/425/217	682032
120	17600	PP1	tempered glass	1 module	>70	-	191/425/217	682049
163	23200	90	PC	1 module	>80	-	191/425/217	682056
194	25800	RM3	tempered glass	1 module	>70	-	191/425/217	682063
194	25800	RM7	tempered glass	1 module	>70	-	191/425/217	682070
194	26300	PP1	tempered glass	1 module	>70	-	191/425/217	682087
194	28100	120	tempered glass	1 module	>70	-	191/425/217	682094
202	32000	90	PC	2 modules	>80	-	385/425/340	682216
217	29400	90	PC	1 module	>80	yes	191/425/217	683060
217	29400	90	PC	1 module	>80	-	191/425/217	682131
233	28900	lambert	tempered glass	1 module	>70	-	191/425/217	683053
233	29000	120	tempered glass	1 module	>70	yes	191/425/217	683046
233	29600	RM3	tempered glass	1 module	>70	yes	191/425/217	682148
233	29600	RM7	tempered glass	1 module	>70	yes	191/425/217	682162
233	29600	RM3	tempered glass	1 module	>70	-	191/425/217	682155
233	29600	RM7	tempered glass	1 module	>70	-	191/425/217	682179
233	29700	PP1	tempered glass	1 module	>70	yes	191/425/217	682186
233	29700	PP1	tempered glass	1 module	>70	-	191/425/217	682193
240	33200	120	tempered glass	2 modules	>70	-	385/425/340	682223
240	34000	RM7	tempered glass	2 modules	>70	-	385/425/340	682230
240	34400	RM3	tempered glass	2 modules	>70	-	385/425/340	682247
240	35200	PP1	tempered glass	2 modules	>70	-	385/425/340	682254
281	37700	90	PC	1 module	>80	-	191/425/217	682209
303	45000	60	PC	3 modules	>80	-	580/425/340	685101
303	48000	90	PC	3 modules	>80	-	580/425/340	682438
326	46400	90	PC	2 modules	>80	-	385/425/340	682261
360	49800	120	tempered glass	3 modules	>70	-	580/425/340	682445
360	51000	RM7	tempered glass	3 modules	>70	-	580/425/340	682452
360	51600	RM3	tempered glass	3 modules	>70	-	580/425/340	682469
360	52800	PP1	tempered glass	3 modules	>70	-	580/425/340	682476
388	50600	120	tempered glass	2 modules	>70	-	385/425/340	682278
388	51600	RM3	tempered glass	2 modules	>70	-	385/425/340	682285
388	51600	RM7	tempered glass	2 modules	>70	-	385/425/340	682292
388	52600	PP1	tempered glass	2 modules	>70	-	385/425/340	683077
404	64000	90	PC	4 modules	>80	-	774/425/340	682780
434	58800	90	PC	2 modules	>80	yes	385/425/340	682339
434	58800	90	PC	2 modules	>80	-	385/425/340	682346
466	58000	120	tempered glass	2 modules	>70	yes	385/425/340	682315
466	58000	120	tempered glass	2 modules	>70	-	385/425/340	682322
466	59200	RM3	tempered glass	2 modules	>70	yes	385/425/340	682353
466	59200	RM7	tempered glass	2 modules	>70	yes	385/425/340	682377
466	59200	RM3	tempered glass	2 modules	>70	-	385/425/340	682360
466	59200	RM7	tempered glass	2 modules	>70	-	385/425/340	682384
466	59400	PP1	tempered glass	2 modules	>70	yes	385/425/340	682391
466	59400	PP1	tempered glass	2 modules	>70	-	385/425/340	682407
480	66400	120	tempered glass	4 modules	>70	-	774/425/340	682797
480	68000	RM3	tempered glass	4 modules	>70	-	774/425/340	683107
480	68000	RM7	tempered glass	4 modules	>70	-	774/425/340	682810
480	70400	PP1	tempered glass	4 modules	>70	-	774/425/340	682827
489	69600	90	PC	3 modules	>80	-	580/425/340	682483
562	75400	90	PC	2 modules	>80	-	385/425/340	682414
582	75900	120	tempered glass	3 modules	>70	-	580/425/340	682490
582	77400	RM3	tempered glass	3 modules	>70	-	580/425/340	682506
582	77400	RM7	tempered glass	3 modules	>70	-	580/425/340	682513
582	78900	PP1	tempered glass	3 modules	>70	-	580/425/340	682520
651	88200	90	PC	3 modules	>80	yes	580/425/340	682551
651	88200	90	PC	3 modules	>80	-	580/425/340	682568
652	92800	90	PC	4 modules	>80	-	774/425/340	682834
699	87000	120	tempered glass	3 modules	>70	yes	580/425/340	682537
699	87000	120	tempered glass	3 modules	>70	-	580/425/340	682544
699	88800	RM3	tempered glass	3 modules	>70	yes	580/425/340	682575
699	88800	RM7	tempered glass	3 modules	>70	yes	580/425/340	682599
699	88800	RM3	tempered glass	3 modules	>70	-	580/425/340	682582
699	88800	RM7	tempered glass	3 modules	>70	-	580/425/340	683084
699	89100	PP1	tempered glass	3 modules	>70	yes	580/425/340	682612
699	89100	PP1	tempered glass	3 modules	>70	-	580/425/340	682629
776	101200	120	tempered glass	4 modules	>70	-	774/425/340	682636
776	103200	RM3	tempered glass	4 modules	>70	-	774/425/340	682643
776	103200	RM7	tempered glass	4 modules	>70	-	774/425/340	682650
776	105200	PP1	tempered glass	4 modules	>70	-	774/425/340	682667
843	109500	15	PC	3 modules	>80	-	580/425/340	685095
843	110700	60	PC	3 modules	>80	-	580/425/340	684838
843	111300	45	PC	3 modules	>80	-	580/425/340	684821
843	113100	90	PC	3 modules	>80	-	580/425/340	682421
868	117600	90	PC	4 modules	>80	yes	774/425/340	682698
868	117600	90	PC	4 modules	>80	-	774/425/340	683091
932	116000	120	tempered glass	4 modules	>70	yes	774/425/340	682674
932	116000	120	tempered glass	4 modules	>70	-	774/425/340	682681
932	118400	RM3	tempered glass	4 modules	>70	yes	774/425/340	682711
932	118400	RM7	tempered glass	4 modules	>70	yes	774/425/340	682735
932	118400	RM3	tempered glass	4 modules	>70	-	774/425/340	682728
932	118400	RM7	tempered glass	4 modules	>70	-	774/425/340	682742
932	118800	PP1	tempered glass	4 modules	>70	yes	774/425/340	682759
932	118800	PP1	tempered glass	4 modules	>70	-	774/425/340	682766
1124	150800	90	PC	4 modules	>80	-	774/425/340	682773

Show more Show less

Accessories

Hide accessories

Index	Accessory name
684791	Protective grid Factor LED 4M RAL7016
684784	Protective grid Factor LED 3M RAL7016
684777	Protective grid Factor LED 2M RAL7016
684760	Protective grid Factor LED 1M RAL7016

Protective grid Factor LED 4M RAL7016 (684791)

Protective grid Factor LED 3M RAL7016 (684784)

Protective grid Factor LED 2M RAL7016 (684777)

* When protective grids are used, the luminaire flux decreases by 1/3 compared to the tested flux declared on the data sheet of the respective floodlight.
