The Tuba IP69K Endura is a cylindrical luminaire for special tasks – where other solutions fail. The Endura version, with a separate power supply box, is designed for extreme temperature conditions – up to 50 (70) °C. It combines the highest tightness, chemical resistance and mechanical durability. Compliance with the IP69K standard means full protection against dust (IP6X) and complete resistance to water under extremely high pressure (100 bar) at 80°C (IPX9K). This makes the luminaire ideal for areas requiring intensive cleaning, including with strong water jets and detergents.

The Tuba IP69K Endura is designed to operate in the most demanding conditions. Made of chemically resistant materials: PMMA and extremely resistant borosilicate glass, it ensures exceptional durability even in aggressive industrial environments. The acid-resistant steel end caps eliminate the risk of corrosion, and its resistance to ammonia and animal gases makes it the ideal solution for breeding and processing facilities. Thanks to the use of a decompression valve, the luminaire can easily withstand sudden temperature changes, and the highest impact resistance class IK10 (for the PC version) guarantees reliability in the most difficult operating conditions.

The Tuba IP69K Endura achieves up to 194 lm/W, meeting the requirements of the highest energy class A. Through-wiring versions, various light distributions and two lengths (630 and 1220 mm) are available. In addition, versions with UGR<19, UGR<22, UGR<25 ensure visual comfort even in demanding applications. Minimalist design, ease of installation and maintenance make the IP69K Tuba a reliable and timeless solution.

UGR < 19
The Unified Glare Rating is an indicator that characterises glare. The lower the Unified Glare Rating (UGR), the lower the glare.

Application

Ideal for places requiring regular high-pressure cleaning, such as car washes, sewage treatment plants, food processing plants and slaughterhouses. It performs excellently in environments with high humidity, extreme negative and positive temperatures, and aggressive vapours – from cold stores and freezers to mushroom farms, animal and plant breeding facilities, and heavy industry. Thanks to its superior chemical, mechanical and thermal resistance, it is a reliable solution for industry.

Options

Rated power of the luminaire [W]	Colour temperature [K]	Luminous flux [lm]	Beam angle [°]	Impact resistance	Diffuser material	DIMM DALI	Light distribution type	Dimensions (H/W/T/S) [mm]	Index
1281/64.5
40	4000	7750	120	IK05	PMMA	-	symmetric	1281/64.5	013652
40	4000	7200	120	IK10	PC	-	symmetric	1281/64.5	013706
40	4000	7750	120	IK06	GLASS	-	symmetric	1281/64.5	013751
40	4000	6750	105	IK05	PMMA	-	symmetric	1281/64.5	013805
40	4000	6200	105	IK10	PC	-	symmetric	1281/64.5	013829
40	4000	6750	105	IK06	GLASS	-	symmetric	1281/64.5	013843
40	4000	7200	105	IK05	PMMA	-	VW	1281/64.5	013867
40	4000	6750	105	IK10	PC	-	VW	1281/64.5	013881
40	4000	7200	105	IK06	GLASS	-	VW	1281/64.5	013904
40	4000	7200	90	IK05	PMMA	-	MW	1281/64.5	013928
40	4000	6750	90	IK10	PC	-	MW	1281/64.5	013942
40	4000	7200	90	IK06	GLASS	-	MW	1281/64.5	013966
40	4000	7150	65	IK05	PMMA	-	SN	1281/64.5	013980
40	4000	6650	65	IK10	PC	-	SN	1281/64.5	014024
40	4000	7150	65	IK06	GLASS	-	SN	1281/64.5	014048
59	4000	11150	120	IK05	PMMA	-	symmetric	1281/64.5	013669
59	4000	11150	120	IK05	PMMA	yes	symmetric	1281/64.5	013676
59	4000	9700	105	IK05	PMMA	yes	symmetric	1281/64.5	013683
59	4000	10400	105	IK05	PMMA	yes	VW	1281/64.5	013690
59	4000	10450	120	IK10	PC	-	symmetric	1281/64.5	013713
59	4000	10450	120	IK10	PC	yes	symmetric	1281/64.5	013720
59	4000	9000	105	IK10	PC	yes	symmetric	1281/64.5	013737
59	4000	9650	105	IK10	PC	yes	VW	1281/64.5	013744
59	4000	11150	120	IK06	GLASS	-	symmetric	1281/64.5	013768
59	4000	11150	120	IK06	GLASS	yes	symmetric	1281/64.5	013775
59	4000	9700	105	IK06	GLASS	yes	symmetric	1281/64.5	013782
59	4000	10400	105	IK06	GLASS	yes	VW	1281/64.5	013799
59	4000	9700	105	IK05	PMMA	-	symmetric	1281/64.5	013812
59	4000	9000	105	IK10	PC	-	symmetric	1281/64.5	013836
59	4000	9700	105	IK06	GLASS	-	symmetric	1281/64.5	013850
59	4000	10400	105	IK05	PMMA	-	VW	1281/64.5	013874
59	4000	9650	105	IK10	PC	-	VW	1281/64.5	013898
59	4000	10400	105	IK06	GLASS	-	VW	1281/64.5	013911
59	4000	10400	90	IK05	PMMA	-	MW	1281/64.5	013935
59	4000	9650	90	IK10	PC	-	MW	1281/64.5	013959
59	4000	10400	90	IK06	GLASS	-	MW	1281/64.5	013973
59	4000	10350	65	IK05	PMMA	-	SN	1281/64.5	013997
59	4000	9600	65	IK10	PC	-	SN	1281/64.5	014031
59	4000	10350	65	IK06	GLASS	-	SN	1281/64.5	014055
59	4000	10400	80	IK05	PMMA	-	SW	1281/64.5	014062
59	4000	9650	80	IK10	PC	-	SW	1281/64.5	014079
59	4000	10400	80	IK06	GLASS	-	SW	1281/64.5	014086
59	4000	10350	35/67	IK05	PMMA	-	CN	1281/64.5	014093
59	4000	9600	35/67	IK10	PC	-	CN	1281/64.5	014116
59	4000	10350	35/67	IK06	GLASS	-	CN	1281/64.5	014130
59	4000	10350	30	IK05	PMMA	-	VN	1281/64.5	014147
59	4000	9600	30	IK10	PC	-	VN	1281/64.5	014154
59	4000	10350	30	IK06	GLASS	-	VN	1281/64.5	014161
59	4000	10100	asymetric	IK05	PMMA	-	SA	1281/64.5	014178
59	4000	9400	asymetric	IK10	PC	-	SA	1281/64.5	014185
59	4000	10100	asymetric	IK06	GLASS	-	SA	1281/64.5	014192
59	4000	10050	butterfly	IK05	PMMA	-	DAN	1281/64.5	014215
59	4000	9350	butterfly	IK10	PC	-	DAN	1281/64.5	014222
59	4000	10050	butterfly	IK06	GLASS	-	DAN	1281/64.5	014239
59	4000	10400	90	IK05	PMMA	yes	MW	1281/64.5	014246
59	4000	9650	90	IK10	PC	yes	MW	1281/64.5	014277
59	4000	10400	90	IK06	GLASS	yes	MW	1281/64.5	014284
59	4000	10350	65	IK05	PMMA	yes	SN	1281/64.5	014291
59	4000	9600	65	IK10	PC	yes	SN	1281/64.5	014314
59	4000	10350	65	IK06	GLASS	yes	SN	1281/64.5	014321
660/64.5
10	4000	1650	120	IK05	PMMA	-	symmetric	660/64.5	013065
10	4000	1550	120	IK10	PC	-	symmetric	660/64.5	013072
10	4000	1650	120	IK06	GLASS	-	symmetric	660/64.5	013089
10	4000	1450	105	IK05	PMMA	-	symmetric	660/64.5	013140
10	4000	1350	105	IK10	PC	-	symmetric	660/64.5	013157
10	4000	1450	105	IK06	GLASS	-	symmetric	660/64.5	013164
10	4000	1550	105	IK05	PMMA	-	VW	660/64.5	013201
10	4000	1450	105	IK10	PC	-	VW	660/64.5	013218
10	4000	1550	105	IK06	GLASS	-	VW	660/64.5	013225
10	4000	1550	90	IK05	PMMA	-	MW	660/64.5	013263
10	4000	1450	90	IK10	PC	-	MW	660/64.5	013270
10	4000	1550	90	IK06	GLASS	-	MW	660/64.5	013287
10	4000	1550	65	IK05	PMMA	-	SN	660/64.5	013324
10	4000	1450	65	IK10	PC	-	SN	660/64.5	013331
10	4000	1550	65	IK06	GLASS	-	SN	660/64.5	013348
32	4000	5550	120	IK05	PMMA	-	symmetric	660/64.5	013003
32	4000	5200	120	IK10	PC	-	symmetric	660/64.5	013041
32	4000	5550	120	IK06	GLASS	-	symmetric	660/64.5	013058
32	4000	4850	105	IK05	PMMA	-	symmetric	660/64.5	013096
32	4000	4500	105	IK10	PC	-	symmetric	660/64.5	013102
32	4000	4850	105	IK06	GLASS	-	symmetric	660/64.5	013133
32	4000	5200	105	IK05	PMMA	-	VW	660/64.5	013171
32	4000	4800	105	IK10	PC	-	VW	660/64.5	013188
32	4000	5200	105	IK06	GLASS	-	VW	660/64.5	013195
32	4000	5200	90	IK05	PMMA	-	MW	660/64.5	013232
32	4000	4800	90	IK10	PC	-	MW	660/64.5	013249
32	4000	5200	90	IK06	GLASS	-	MW	660/64.5	013256
32	4000	5150	65	IK05	PMMA	-	SN	660/64.5	013294
32	4000	4800	65	IK10	PC	-	SN	660/64.5	013300
32	4000	5150	65	IK06	GLASS	-	SN	660/64.5	013317
32	4000	5200	80	IK05	PMMA	-	SW	660/64.5	013355
32	4000	4800	80	IK10	PC	-	SW	660/64.5	013362
32	4000	5200	80	IK06	GLASS	-	SW	660/64.5	013379
32	4000	5150	35/67	IK05	PMMA	-	CN	660/64.5	013386
32	4000	4800	35/67	IK10	PC	-	CN	660/64.5	013393
32	4000	5150	35/67	IK06	GLASS	-	CN	660/64.5	013409
32	4000	5150	30	IK05	PMMA	-	VN	660/64.5	013416
32	4000	4800	30	IK10	PC	-	VN	660/64.5	013423
32	4000	5150	30	IK06	GLASS	-	VN	660/64.5	013430
32	4000	5050	asymetric	IK05	PMMA	-	SA	660/64.5	013447
32	4000	4700	asymetric	IK10	PC	-	SA	660/64.5	013454
32	4000	5050	asymetric	IK06	GLASS	-	SA	660/64.5	013461
32	4000	5000	butterfly	IK05	PMMA	-	DAN	660/64.5	013478
32	4000	4650	butterfly	IK10	PC	-	DAN	660/64.5	013485
32	4000	5000	butterfly	IK06	GLASS	-	DAN	660/64.5	013492
32	4000	5550	120	IK05	PMMA	yes	symmetric	660/64.5	013508
32	4000	4850	105	IK05	PMMA	yes	symmetric	660/64.5	013515
32	4000	5200	105	IK05	PMMA	yes	VW	660/64.5	013522
32	4000	5200	120	IK10	PC	yes	symmetric	660/64.5	013539
32	4000	4500	105	IK10	PC	yes	symmetric	660/64.5	013546
32	4000	4800	105	IK10	PC	yes	VW	660/64.5	013553
32	4000	5550	120	IK06	GLASS	yes	symmetric	660/64.5	013560
32	4000	4850	105	IK06	GLASS	yes	symmetric	660/64.5	013577
32	4000	5200	105	IK06	GLASS	yes	VW	660/64.5	013584
32	4000	5200	90	IK05	PMMA	yes	MW	660/64.5	013591
32	4000	4800	90	IK10	PC	yes	MW	660/64.5	013607
32	4000	5200	90	IK06	GLASS	yes	MW	660/64.5	013614
32	4000	5150	65	IK05	PMMA	yes	SN	660/64.5	013621
32	4000	4800	65	IK10	PC	yes	SN	660/64.5	013638
32	4000	5150	65	IK06	GLASS	yes	SN	660/64.5	013645

Show more Show less

Accessories

Hide accessories

Index	Accessory name
778254	Tuba IP69K 3P connector set
778261	Connector set Tuba IP69K 5P DALI

Tuba IP69K 3P connector set (778254)

Connector set Tuba IP69K 5P DALI (778261)
