Dot CS LED

Surface-mounted autonomous emergency luminaire with integrated, energy-saving LED light module.

Technical specifications

Light source
LED
Colour temperature
5000K
Mounting version
surface
Application
  • commercial
  • educational
  • HoReCa
  • medical
  • residential
  • industrial
  • sports
  • art and culture
  • architectural
  • office
LEDIIip23CE

Specification

Surface-mounted autonomous emergency luminaire with integrated, energy-saving LED light module. Body made of polycarbonate (PC). Optical system available in 3 variants: basic, corridor, open space. Luminaire is fitted with batteries with 1h, 2h or 3h emergency operation time. The luminaire is using Ni-Mh or Ni-Cd battery with a voltage of 3.6V and 24 hours of full charge with a manual or automatic test function (AT).

Application

An autonomous emergency luminaire is mainly used for illumination of escape routes and fire protection devices after a power failure, i.e. in emergency mode. Especially recommended everywhere, where it is necessary to install emergency lighting within the scope of modernization of the existing system. Successfully replaces luminaires with embedded emergency modules. Due to additional sealing, the luminaire achieves IP65 tightness and may be used in places with increased humidity or outdoors under the roofing.

Versions:

M – Maintained

NM- Non-maintained

AT – Autotest

Options

Nominal
power [W]
Colour
temperature [K]
Luminous
flux [lm]
Emergency
lighting [h]
Operating
mode
Autotest
Index
DOT CS LED corridor
1 5000 140 1 NM - 550188
1 5000 140 1 NM yes 550201
1 5000 140 1 M - 550225
1 5000 140 2 NM - 550249
1 5000 140 2 NM yes 550263
1 5000 140 2 M - 550287
1 5000 140 3 NM - 550300
1 5000 140 3 NM yes 550324
1 5000 140 3 M - 550348
2 5000 260 1 NM - 550195
2 5000 260 1 NM yes 550218
2 5000 260 1 M - 550232
2 5000 260 2 NM - 550256
2 5000 260 2 NM yes 550270
2 5000 260 2 M - 550294
2 5000 260 3 NM - 550317
2 5000 260 3 NM yes 550331
2 5000 260 3 M - 550355
DOT CS LED general
1 5000 130 1 NM - 550003
1 5000 130 1 NM yes 550027
1 5000 130 1 M - 550041
1 5000 130 2 NM - 550065
1 5000 130 2 NM yes 550089
1 5000 130 2 M - 550102
1 5000 130 3 NM - 550126
1 5000 130 3 NM yes 550140
1 5000 130 3 M - 550164
2 5000 250 1 NM - 550010
2 5000 250 1 NM yes 550034
2 5000 250 1 M - 550058
2 5000 250 2 NM - 550072
2 5000 250 2 NM yes 550096
2 5000 250 2 M - 550119
2 5000 250 3 NM - 550133
2 5000 250 3 NM yes 550157
2 5000 250 3 M - 550171
DOT CS LED open space
1 5000 140 1 NM - 550362
1 5000 140 1 NM yes 550386
1 5000 140 1 M - 550409
1 5000 140 2 NM - 550423
1 5000 140 2 NM yes 550447
1 5000 140 2 M - 550461
1 5000 140 3 NM - 550485
1 5000 140 3 NM yes 550508
1 5000 140 3 M - 550522
2 5000 260 1 NM - 550379
2 5000 260 1 NM yes 550393
2 5000 260 1 M - 550416
2 5000 260 2 NM - 550430
2 5000 260 2 NM yes 550454
2 5000 260 2 M - 550478
2 5000 260 3 NM - 550492
2 5000 260 3 NM yes 550515
2 5000 260 3 M - 550539
