SQ 600 LED Clue IoT is a new line of square luminaires. The construction, designed from scratch, introduces new solutions ensuring excellent lighting parameters. The body is made of plastic, therefore it is characterized by low weight. The diffuser provides excellent light transmission. The integrated LED module guarantees low power consumption and all the advantages of modern LED light sources.

The luminaire is available in 2 versions:

  • - with OPAL diffuser - providing soft light;
  • - with PRM diffuser - with higher luminous efficiency and low glare UGR <19 (18W, 24W, 32W versions).
  • Available options:

  • - RCR sensor - sensor used for motion detection, without twilight detection option; uses microwaves for detection (active sensor),
  • - control in the DALI standard,
  • - CORRIDOR corridor function (RCR + DALI).
  • The ingress protection- depends on the method of installation:

  • - surface mounted - IP20,
  • - flush-mounted - IP44/20.
  • Application

    Surface-mounted luminaire with the possibility of flush-mounting in modular ceilings and in plasterboard ceilings (using plasterboard recessing kit) is especially recommended for offices, spacious corridors, and public spaces.

    Other products from the Sq LED family

    See our luminaires on the BIMobject platform

    Options
    Nominal power [W]Luminous flux [lm]Colour temperature [K]Diffuser typeMotion sensorDIMM DALIIndex
    OPAL
    29 2900 3000 OPAL yes yes 669958
    29 3100 4000 OPAL yes yes 669965
    29 2900 3000 OPAL - yes 670664
    29 3100 4000 OPAL - yes 670671
    29 2900 3000 OPAL yes - 670862
    29 3100 4000 OPAL yes - 670879
    37 3700 4000 OPAL yes yes 670527
    37 3500 3000 OPAL yes yes 670534
    37 3700 4000 OPAL - yes 670701
    37 3500 3000 OPAL - yes 670718
    37 3500 3000 OPAL yes - 670909
    37 3700 4000 OPAL yes - 670916
    45 4100 3000 OPAL yes yes 670565
    45 4400 4000 OPAL yes yes 670572
    45 4100 3000 OPAL - yes 670749
    45 4400 4000 OPAL - yes 670756
    45 4100 3000 OPAL yes - 670947
    45 4400 4000 OPAL yes - 670954
    PRM
    18 2650 3000 PRM yes yes 669897
    18 2800 4000 PRM yes yes 669941
    18 2650 3000 PRM - yes 670626
    18 2800 4000 PRM - yes 670633
    18 2650 3000 PRM yes - 670824
    18 2800 4000 PRM yes - 670831
    24 3400 3000 PRM yes yes 669903
    24 3700 4000 PRM yes yes 669910
    24 3400 3000 PRM - yes 670640
    24 3700 4000 PRM - yes 670657
    24 3400 3000 PRM yes - 670848
    24 3700 4000 PRM yes - 670855
    32 4400 3000 PRM yes yes 670503
    32 4700 4000 PRM yes yes 670510
    32 4400 3000 PRM - yes 670688
    32 4700 4000 PRM - yes 670695
    32 4400 3000 PRM yes - 670886
    32 4700 4000 PRM yes - 670893
    42 5600 3000 PRM yes yes 670541
    42 6000 4000 PRM yes yes 670558
    42 5600 3000 PRM - yes 670725
    42 6000 4000 PRM - yes 670732
    42 5600 3000 PRM yes - 670923
    42 6000 4000 PRM yes - 670930
    52 6350 3000 PRM yes yes 670589
    52 6800 4000 PRM yes yes 670596
    52 6350 3000 PRM - yes 670763
    52 6800 4000 PRM - yes 670770
    52 6350 3000 PRM yes - 670961
    52 6800 4000 PRM yes - 670978
    60 8400 4000 PRM yes yes 670602
    60 8400 4000 PRM - yes 670787
    60 8400 4000 PRM yes - 670985
    73 10900 4000 PRM - yes 670619
    73 10900 4000 PRM - yes 670794
    73 10900 4000 PRM yes - 670992
     NameIndex
    plasterboard recessing kit 630x630 white 999543

    COMPACT LED EVO P Ramka adapter KG 630x630 mm
