Dione LED Plus IoT

Designed from scratch surface mounted, round LED luminaire with integrated, energy saving LED module.

Technical specifications

Light source	LED
Colour temperature	3000K
Diffuser type	OPAL
Mounting version	surface
Application	commercial educational residential art and culture office

LEDIik10ip65pzhCE

Ask about this product

Options

Downloads

Specification

Designed from scratch surface mounted, round LED luminaire with integrated, energy-saving LED panel. The fitting introduces new solutions to improve the light distribution and balance of the temperatures. It is characterized by high lighting efficiency and very high IP65 ingress protection. Specially profiled diffuser made of vandal-resistant PC allows keeping the highest degree of impact resistance IK10. It uses a number of proven solutions affecting the speed and ease of the assembly (suspension kit for the diffuser, readiness for through wiring) and component security: diffuser integrated with LED panel. Also available is a body made of ASA material, with excellent UV resistance, suitable for outdoor use. The ceiling ring is used to cover the gap between the luminaire and the surface on which it is mounted. The accessory can be used in prison cells.

Luminaires of the PLUS variant line are fitted with branded components of recognized global manufacturers. It features extended life and warranty, increased light efficiency, and optimal use of electricity (Power Factor).

The MULTI luminaire version allows individual configuration: thanks to the built-in microswitch, it is possible to choose one of three settings (nominal power of the fitting [W] / luminous flux of the fitting [lm]).

Specification IoT

The IoT BT RCR HYT DALI version has: a built-in BT HYT module that allows you to program functions in the Lena Lighting Clue app and control in real time; RCR motion and daylight sensor hidden under the shade and DALI driver for dimming the light source.

Application

Surface-mounted wall or ceiling luminaire intended for indoor use (utility rooms, staircases, circulation routes) or outdoor. It is also available in a version with an RF motion detector which is especially recommended for use in spaces open to the public.

Other products from the Dione LED family

Options

Nominal power [W]	Luminous flux [lm]	Version	Dimensions (H/W/T/S) [mm]	Index
25	2700	RCR RF	340/115	943607
30	3400	RCR RF	340/115	943591

Accessories

Hide accessories

Index	Accessory name
120DL118	Ceiling ring Dione LED steel 1.5 white matt RAL 9003 painted vandal resistant

Ceiling ring Dione LED steel 1.5 white matt RAL 9003 painted vandal resistant (120DL118)
