Downloads

Specification

Mounting on a rail system, increases the range of applications of this lamp and allows the user to make rearrangements, even after installation. The lamp has an adapter equipped with mechanical catches that make it easy to plug in, unplug and move the lamps, while ensuring that the fixture is securely held in the rail. The lamps, together with appropriately selected rails and components, allow for ceiling or wall mounting. The Terrano S lamp is perfect as a source of light in offices, stores, dressing rooms, in passageways.

DALI version available on request.

Application

Mounting on a rail system, increases the range of applications of this lamp and allows the user to make rearrangements, even after installation. The lamp has an adapter equipped with mechanical catches that make it easy to plug in, unplug and move the lamps, while ensuring that the fixture is securely held in the rail. The lamps, together with appropriately selected rails and components, allow for ceiling or wall mounting. The Terrano S lamp is perfect as a source of light in offices, stores, dressing rooms, in passageways.

Luminaire for trunking installation

The luminaire has an adaptor fitted with mechanical catches that make it easy to clip in, out and move the luminaires around, ensuring that the luminaire is securely held in the rail.

Key differences between the S/R and S versions:

Terrano S:
The 566mm long version allows 360° rotation around its axis, the longer version does not.

Terrano S/R:
The 630mm-long version allows 360° rotation around its axis and 45° rotation of the light system. The 1180mm version only allows for 45° rotation of the lighting system.

Options

Rated power of the luminaire [W]	Luminous flux [lm]	Colour temperature [K]	Colour of the body	Dimensions (H/W/T/S) [mm]	Index
TERRANO S 48/1117/69
28	3000	3000	black	48/1117/69	577161
28	3200	4000	black	48/1117/69	577246
28	3300	3000	white	48/1117/69	577208
28	3500	4000	white	48/1117/69	577284
35	3700	3000	black	48/1117/69	577178
35	3900	4000	black	48/1117/69	577253
35	4100	3000	white	48/1117/69	577215
35	4300	4000	white	48/1117/69	577291
40	4100	3000	black	48/1117/69	577185
40	4400	4000	black	48/1117/69	577260
40	4600	3000	white	48/1117/69	577222
40	4800	4000	white	48/1117/69	577307
56	5400	3000	black	48/1117/69	577192
56	5700	4000	black	48/1117/69	577277
56	5900	3000	white	48/1117/69	577239
56	6300	4000	white	48/1117/69	577314
TERRANO S 48/566/69
9	1050	3000	black	48/566/69	577000
9	1100	4000	black	48/566/69	577086
9	1150	3000	white	48/566/69	577048
9	1200	4000	white	48/566/69	577123
16	1750	3000	black	48/566/69	577017
16	1850	4000	black	48/566/69	577093
16	1950	3000	white	48/566/69	577055
16	2050	4000	white	48/566/69	577130
22	2300	3000	black	48/566/69	577024
22	2400	4000	black	48/566/69	577109
22	2500	3000	white	48/566/69	577062
22	2650	4000	white	48/566/69	577147
28	2700	3000	black	48/566/69	577031
28	2850	4000	black	48/566/69	577116
28	2950	3000	white	48/566/69	577079
28	3150	4000	white	48/566/69	577154
