Phobos LED

Surface-mounted, round LED fitting with very high diffuser diameter, high luminous flux (78 lm/W), and even light distribution.

Technical specifications

Light source
LED
Colour temperature
  • 3000K
  • 4000K
Diffuser type
OPAL
Mounting version
surface
Application
  • HoReCa
  • residential
LEDIik08ip40CE

Specification

Surface-mounted, round LED fitting with very high diffuser diameter, high luminous flux (78 lm/W), and even light distribution. Includes an integrated energy-saving light source LED. Galvanized steel base, powder-coated white; light, white acrylic diffuser made using termoforming method. A simple pawl-based mounting system does not require any additional tools and safeguards the diffuser against uncontrolled fall. The luminaire may be used to replace standard four-lamp fittings in irregular-shaped rooms. Designed to work with a radio motion sensor or the DALI system. Color temperature 3000K/4000K, CRI>80, lifespan of LED 81 000h (L70B50) ta= 25 ºC.

Application

Surface-mounted fitting intended for indoor use characterized by even light distribution and good surface lighting. Particularly suitable as a general light source in representative rooms and passageways. Thanks to exceptional lighting parameters, possible integration with the DALI system, and decorative qualities, the product will surely prove its worth in large conference halls.

Options

Nominal
power [W]
Colour
temperature [K]
Luminous
flux [lm]
Diffuser
type
Motion
sensor
DIMM
DALI
Emergency
lighting [h]
Index
PHOBOS LED 28W
28 4000 3500 OPAL - - - 462443
28 3000 3250 OPAL - - - 462450
28 4000 3500 OPAL - - 3 462504
28 3000 3250 OPAL - - 3 462511
28 4000 3500 OPAL yes - - 462467
28 3000 3250 OPAL yes - - 462474
28 4000 3500 OPAL - yes - 462481
28 3000 3250 OPAL - yes - 462498
PHOBOS LED 36W
36 4000 4400 OPAL - - - 462368
36 3000 4100 OPAL - - - 462375
36 4000 4400 OPAL - - 3 462429
36 3000 4100 OPAL - - 3 462436
36 4000 4400 OPAL yes - - 462382
36 3000 4100 OPAL yes - - 462399
36 4000 4400 OPAL - yes - 462405
36 3000 4100 OPAL - yes - 462412
PHOBOS LED 45W
45 4000 5500 OPAL - - - 462306
45 3000 5100 OPAL - - - 462313
45 4000 5500 OPAL yes - - 462320
45 3000 5100 OPAL yes - - 462337
45 4000 5500 OPAL - yes - 462344
45 3000 5100 OPAL - yes - 462351
PHOBOS LED 53W
53 4000 6300 OPAL - - - 462245
53 3000 5850 OPAL - - - 462252
53 4000 6300 OPAL yes - - 462269
53 3000 5850 OPAL yes - - 462276
53 4000 6300 OPAL - yes - 462283
53 3000 5850 OPAL - yes - 462290
PHOBOS LED 60W
60 4000 7400 OPAL - - - 462184
60 3000 6900 OPAL - - - 462191
60 4000 7400 OPAL yes - - 462207
60 3000 6900 OPAL yes - - 462214
60 4000 7400 OPAL - yes - 462221
60 3000 6900 OPAL - yes - 462238
