Skver LED S (Z1 MF)

Skver LED S (Z1 MF) modular, decorative, innovative park and city LED luminaire with tool-free access to the equipment compartment, equipped with a tool-free service plate compliant with the ZhagaBook 13 and 15 standard, adapted for both top and boom mounting. Luminaire with indicator ULR = 0.

Technical specifications

Light source	LED
Colour temperature	4000K
Diffuser type	transparent
Mounting version	side entry or post top
Application	parkings and bicycle paths streets and roads public areas non-public estate roads roads, squares, internal and private areas

LED220-240vIIik10ip66enecENEC PlusCEZhaga-D4i EPD

Ask about this product

Options

Downloads

Specification

Skver LED S (Z1 MF) modular, decorative, innovative park and city LED luminaire with tool-free access to the equipment compartment, equipped with a tool-free service plate compliant with the ZhagaBook 13 and 15 standard, adapted for both top and boom mounting. Made of pressure-formed aluminum, equipped with a flat glass shade, characterized by ULR = 0, maximum resistance to mechanical impact and increased color rendering index. The luminaire is available in variants with omnidirectional and directed lighting. The luminaire allows the use of dedicated functional accessories in the form of a screen that limits disturbing glare.

Distinguishing features:

distinctive urban design of a round luminaire
architectural quality of workmanship
omnidirectional and directed distribution
available variants in standard (CRI70) and increased color rendering index (CRI80)
highest degree of resistance IK10
tool-free access to the equipment chamber
adjustable mounting bracket enabling mounting of the luminaire both on poles and on an extension arm in the range of fi 48 - fi 76
possibility of equipping with a dedicated accessory reducing glare
possibility of equipping the luminaire with a Zhaga connector compliant with ZD4i
certificates: ENEC, ENEC+, ZD4i, EPD environmental declaration
tool-free service plate, compliant with the ZhagaBook 13 and 15 standard
knife connector cutting off voltage during service work
luminaire with indicator ULR = 0

Application

Skver LED S (Z1 MF) is ideal for biologically active spaces, where the protection of the dark sky plays a special role, such as parks, squares, urban green islands, urban interiors in accordance with the photometric project, pedestrian routes, residential roads, parking lots and gardens. The luminaire is also suitable for lighting streets and roads of class M4 and M5.

Thanks to the ULR = 0 index, it protects the urban ecosystem from excessive light emission into the upper half-space, restoring the dark night sky over cities.

Options

Rated power of the luminaire [W]	Luminous flux [lm]	Luminous efficacy [lm/W]	Colour temperature [K]	Colour rendering index	Electrical protection class	Optics	DIMM DALI	Dimensions (H/W/T/S) [mm]	Index
Skver LED S (Z1 MF) MLS
8	975	127	4000	>80	II	MLS	yes	461/360/188	800009
8	975	127	4000	>80	II	MLS	yes	461/360/188	800542
10	1325	137	4000	>80	II	MLS	yes	461/360/188	800016
10	1325	137	4000	>80	II	MLS	yes	461/360/188	800559
12	1575	137	4000	>80	II	MLS	yes	461/360/188	800023
12	1575	137	4000	>80	II	MLS	yes	461/360/188	800566
14	1850	138	4000	>80	II	MLS	yes	461/360/188	800030
14	1850	138	4000	>80	II	MLS	yes	461/360/188	800573
15	1975	138	4000	>80	II	MLS	yes	461/360/188	800047
15	1975	138	4000	>80	II	MLS	yes	461/360/188	800580
16	2125	139	4000	>80	II	MLS	yes	461/360/188	800054
16	2125	139	4000	>80	II	MLS	yes	461/360/188	800597
18	2425	139	4000	>80	II	MLS	yes	461/360/188	800061
18	2425	139	4000	>80	II	MLS	yes	461/360/188	800603
21	2800	139	4000	>80	II	MLS	yes	461/360/188	800078
21	2800	139	4000	>80	II	MLS	yes	461/360/188	800610
23	3100	140	4000	>80	II	MLS	yes	461/360/188	800085
23	3100	140	4000	>80	II	MLS	yes	461/360/188	800627
24	3225	140	4000	>80	II	MLS	yes	461/360/188	800092
24	3225	140	4000	>80	II	MLS	yes	461/360/188	800634
25	3350	140	4000	>80	II	MLS	yes	461/360/188	800108
25	3350	140	4000	>80	II	MLS	yes	461/360/188	800641
26	3500	139	4000	>80	II	MLS	yes	461/360/188	800115
26	3500	139	4000	>80	II	MLS	yes	461/360/188	800658
28	3750	139	4000	>80	II	MLS	yes	461/360/188	800122
28	3750	139	4000	>80	II	MLS	yes	461/360/188	800665
29	3875	139	4000	>80	II	MLS	yes	461/360/188	800139
29	3875	139	4000	>80	II	MLS	yes	461/360/188	800672
30	4050	140	4000	>80	II	MLS	yes	461/360/188	800146
30	4050	140	4000	>80	II	MLS	yes	461/360/188	800689
31	4150	139	4000	>80	II	MLS	yes	461/360/188	800153
31	4150	139	4000	>80	II	MLS	yes	461/360/188	800696
33	4350	137	4000	>80	II	MLS	yes	461/360/188	800160
33	4350	137	4000	>80	II	MLS	yes	461/360/188	800702
34	4475	137	4000	>80	II	MLS	yes	461/360/188	800177
34	4475	137	4000	>80	II	MLS	yes	461/360/188	800719
35	4600	137	4000	>80	II	MLS	yes	461/360/188	800184
35	4600	137	4000	>80	II	MLS	yes	461/360/188	800726
36	4725	137	4000	>80	II	MLS	yes	461/360/188	800191
36	4725	137	4000	>80	II	MLS	yes	461/360/188	800733
37	4900	138	4000	>80	II	MLS	yes	461/360/188	800207
37	4900	138	4000	>80	II	MLS	yes	461/360/188	800740
39	5200	138	4000	>80	II	MLS	yes	461/360/188	800214
39	5200	138	4000	>80	II	MLS	yes	461/360/188	800757
44	5600	132	4000	>80	II	MLS	yes	461/360/188	800221
44	5600	132	4000	>80	II	MLS	yes	461/360/188	800764
47	5925	131	4000	>80	II	MLS	yes	461/360/188	800238
47	5925	131	4000	>80	II	MLS	yes	461/360/188	800771
50	6250	130	4000	>80	II	MLS	yes	461/360/188	800245
50	6250	130	4000	>80	II	MLS	yes	461/360/188	800788
52	6425	129	4000	>80	II	MLS	yes	461/360/188	800252
52	6425	129	4000	>80	II	MLS	yes	461/360/188	800795
54	6625	128	4000	>80	II	MLS	yes	461/360/188	800269
54	6625	128	4000	>80	II	MLS	yes	461/360/188	800801
Skver LED S (Z1 MF) RM7
8	1125	146	4000	>70	II	RM7	yes	461/360/188	802164
8	1125	146	4000	>70	II	RM7	yes	461/360/188	802706
10	1500	156	4000	>70	II	RM7	yes	461/360/188	802171
10	1500	156	4000	>70	II	RM7	yes	461/360/188	802713
12	1800	156	4000	>70	II	RM7	yes	461/360/188	802188
12	1800	156	4000	>70	II	RM7	yes	461/360/188	802720
14	2050	153	4000	>70	II	RM7	yes	461/360/188	802195
14	2050	153	4000	>70	II	RM7	yes	461/360/188	802737
15	2250	155	4000	>70	II	RM7	yes	461/360/188	802201
15	2250	155	4000	>70	II	RM7	yes	461/360/188	802744
16	2400	155	4000	>70	II	RM7	yes	461/360/188	802218
16	2400	155	4000	>70	II	RM7	yes	461/360/188	802751
18	2675	155	4000	>70	II	RM7	yes	461/360/188	802225
18	2675	155	4000	>70	II	RM7	yes	461/360/188	802768
21	3150	156	4000	>70	II	RM7	yes	461/360/188	802232
21	3150	156	4000	>70	II	RM7	yes	461/360/188	802775
23	3450	156	4000	>70	II	RM7	yes	461/360/188	802249
23	3450	156	4000	>70	II	RM7	yes	461/360/188	802782
24	3600	156	4000	>70	II	RM7	yes	461/360/188	802256
24	3600	156	4000	>70	II	RM7	yes	461/360/188	802799
25	3725	155	4000	>70	II	RM7	yes	461/360/188	802263
25	3725	155	4000	>70	II	RM7	yes	461/360/188	802805
26	3875	155	4000	>70	II	RM7	yes	461/360/188	802270
26	3875	155	4000	>70	II	RM7	yes	461/360/188	802812
28	4150	154	4000	>70	II	RM7	yes	461/360/188	802287
28	4150	154	4000	>70	II	RM7	yes	461/360/188	802829
29	4275	153	4000	>70	II	RM7	yes	461/360/188	802294
29	4275	153	4000	>70	II	RM7	yes	461/360/188	802836
30	4425	153	4000	>70	II	RM7	yes	461/360/188	802300
30	4425	153	4000	>70	II	RM7	yes	461/360/188	802843
31	4550	153	4000	>70	II	RM7	yes	461/360/188	802317
31	4550	153	4000	>70	II	RM7	yes	461/360/188	802850
33	4750	149	4000	>70	II	RM7	yes	461/360/188	802324
33	4750	149	4000	>70	II	RM7	yes	461/360/188	802867
34	4875	149	4000	>70	II	RM7	yes	461/360/188	802331
34	4875	149	4000	>70	II	RM7	yes	461/360/188	802874
35	5025	149	4000	>70	II	RM7	yes	461/360/188	802348
35	5025	149	4000	>70	II	RM7	yes	461/360/188	802881
36	5150	149	4000	>70	II	RM7	yes	461/360/188	802355
36	5150	149	4000	>70	II	RM7	yes	461/360/188	802898
37	5275	148	4000	>70	II	RM7	yes	461/360/188	802362
37	5275	148	4000	>70	II	RM7	yes	461/360/188	802904
39	5500	147	4000	>70	II	RM7	yes	461/360/188	802379
39	5500	147	4000	>70	II	RM7	yes	461/360/188	802911
44	5950	141	4000	>70	II	RM7	yes	461/360/188	802386
44	5950	141	4000	>70	II	RM7	yes	461/360/188	802928
47	6300	139	4000	>70	II	RM7	yes	461/360/188	802393
47	6300	139	4000	>70	II	RM7	yes	461/360/188	802935
50	6575	137	4000	>70	II	RM7	yes	461/360/188	802409
50	6575	137	4000	>70	II	RM7	yes	461/360/188	802942
52	6825	136	4000	>70	II	RM7	yes	461/360/188	802416
52	6825	136	4000	>70	II	RM7	yes	461/360/188	802959
54	7025	135	4000	>70	II	RM7	yes	461/360/188	802423
54	7025	135	4000	>70	II	RM7	yes	461/360/188	802966
