Control modules

Control modules allow for intelligent control of LED lamps. They can be mounted directly in the lamp or in the wall. They can also replicate the BT mesh network signal and be a reference object for network time.

Technical specifications

Ask about this product

Options

Downloads

Specification

The BT control module, when connected to the DALI driver, allows for full control over the fixture. Its small dimensions allow it to be placed in an electrical box or in a lamp, making it an IoT lamp.

Application

Control modules can be mounted in lamps, flush-mounted electrical boxes and suspended ceilings.

Options

Index	Name of part	System	Dimming control	Ingress protection	CE declaration of conformity
624544	BT HYT NEMA DALI Clue City IoT controller	Clue City	yes	IP65	CE
624551	BT TK HYT NEMA DALI Clue City IoT controller	Clue City	yes	IP65	CE
624711	Controller BT HYT 100mA DALI HBTD8200D/F+ant IoT	Clue	yes	IP20	CE
624933	Modul TK BT HYT HTG02/F +ant IoT	Clue	-	IP20	CE
625152	TK BT HYT HTG02/F +ant module in IP67 IoT box	Clue City	-	IP67	CE
625169	LTE FON NEMA LCU16LTE CAT1 Clue City+ IoT controller	Clue City+	yes	IP65	CE
625596	FON ZHAGA LCU71LTE CAT1 Clue City+ IoT LTE controller	Clue City+	yes	IP66	CE
IOT0021	RJ12 BT HYT base controller 1-10V HC038V/BT+ant IoT	Clue	yes	IP20	CE
IOT0032	BT HYT 4-Button HBTD8200P/F IoT Controller	Clue	yes	IP20	CE
IOT0036	BT HYT NC/NO HBTD8200VFC/F IoT controller	Clue	-	IP20	CE
IOT0089	TRI ZHAGA SIDEREA CIS 30 GPS RF868 DA2 RF controller (28003929) IoT	SIDEREA	yes	IP66	CE
W02996	TK BT HYT HTG01/F IoT Module	Clue	-	IP20	CE
WSE0011	BT HYT DALI HBTD8200D/F IoT controller	Clue	yes	IP20	CE
WSE0014	BT HYT 1-10V HBTD8200V/F IoT controller	Clue	yes	IP20	CE
WSE0024	DALI Casambi basicDIM Wireless G2 Tridonic 28003540 IoT BT controller	CASAMBI	yes	IP20	CE
WSE0027	BT HYT ZHAGA DALI HBTD15/E IoT controller	Clue City	yes	IP66	CE
WSEL116	RJ12 BT HYT DALI HCD038/BT IoT base controller	Clue	yes	IP20	CE
WSEL420	Controller BT HYT ON/OFF HBTD8200S/F IoT	Clue	no	IP20	CE
IOT0055	FONDA LCU71LW ZHAGA IoT controller	Clue City+	yes	IP65	CE
