Specification

A recessed luminaire with classic proportions and modern design, intended for installation in modular ceilings. The luminaire is available in three lengths: 595mm, 1195mm, 1795mm. The housing of the luminaire is made of an anodized aluminum profile in gray or an aluminum profile painted in white or black (other colors available on request). The optical system is in the form of a dedicated, flexible opal diffuser that evenly illuminates the luminaire, with a PRM prismatic diffuser. The luminaire is equipped with a complete mounting system enabling quick and easy installation in modular ceilings (SM).

Application

The luminaire is dedicated to indoor use. It is applied as the source of the main light and is conducive to office work requiring concentration of eyesight. Classic design, energy-saving LED modules, and the possibility of cooperation with external lighting control systems in the DALI standard dedicate the lamp to be used in modern office buildings of the A+ class, with particular consideration of representative rooms, conference halls, passageways.

Other products from the Baris LED family

See our luminaires on the BIMobject platform

Options
Rated power of the luminaire [W]Colour temperature [K]Luminous flux [lm]Diffuser typeColour of the bodyDIMM DALIDimensions [mm]Index
1193/69/60
18 4000 1900 OPAL grey - 1193/69/60 928246
18 4000 1900 PRM grey - 1193/69/60 928253
18 4000 1900 OPAL white - 1193/69/60 928284
18 4000 1900 PRM white - 1193/69/60 928291
18 4000 1900 OPAL black - 1193/69/60 928321
18 4000 1900 PRM black - 1193/69/60 928338
18 4000 1900 OPAL grey yes 1193/69/60 928369
18 4000 1900 PRM grey yes 1193/69/60 928376
18 4000 1900 OPAL white yes 1193/69/60 928406
18 4000 1900 PRM white yes 1193/69/60 928413
18 4000 1900 OPAL black yes 1193/69/60 928444
18 4000 1900 PRM black yes 1193/69/60 928451
18 3000 1800 OPAL grey - 1193/69/60 928963
18 3000 1800 PRM grey - 1193/69/60 928970
18 3000 1800 OPAL white - 1193/69/60 929007
18 3000 1800 PRM white - 1193/69/60 929014
18 3000 1800 OPAL black - 1193/69/60 929045
18 3000 1800 PRM black - 1193/69/60 929052
18 3000 1800 OPAL grey yes 1193/69/60 929083
18 3000 1800 PRM grey yes 1193/69/60 929090
18 3000 1800 OPAL white yes 1193/69/60 929120
18 3000 1800 PRM white yes 1193/69/60 929137
18 3000 1800 OPAL black yes 1193/69/60 929168
18 3000 1800 PRM black yes 1193/69/60 929175
30 4000 3000 OPAL grey - 1193/69/60 928260
30 4000 3000 PRM grey - 1193/69/60 928277
30 4000 3000 OPAL white - 1193/69/60 928307
30 4000 3000 PRM white - 1193/69/60 928314
30 4000 3000 OPAL black - 1193/69/60 928345
30 4000 3000 PRM black - 1193/69/60 928352
30 4000 3000 OPAL grey yes 1193/69/60 928383
30 4000 3000 PRM grey yes 1193/69/60 928390
30 4000 3000 OPAL white yes 1193/69/60 928420
30 4000 3000 PRM white yes 1193/69/60 928437
30 4000 3000 OPAL black yes 1193/69/60 928468
30 4000 3000 PRM black yes 1193/69/60 928475
30 3000 2800 OPAL grey - 1193/69/60 928987
30 3000 2800 PRM grey - 1193/69/60 928994
30 3000 2800 OPAL white - 1193/69/60 929021
30 3000 2800 PRM white - 1193/69/60 929038
30 3000 2800 OPAL black - 1193/69/60 929069
30 3000 2800 PRM black - 1193/69/60 929076
30 3000 2800 OPAL grey yes 1193/69/60 929106
30 3000 2800 PRM grey yes 1193/69/60 929113
30 3000 2800 OPAL white yes 1193/69/60 929144
30 3000 2800 PRM white yes 1193/69/60 929151
30 3000 2800 OPAL black yes 1193/69/60 929182
30 3000 2800 PRM black yes 1193/69/60 929199
1793/69/60
26 4000 2700 OPAL grey - 1793/69/60 928482
26 4000 2700 PRM grey - 1793/69/60 928499
26 4000 2700 OPAL white - 1793/69/60 928529
26 4000 2700 PRM white - 1793/69/60 928536
26 4000 2700 OPAL black - 1793/69/60 928567
26 4000 2700 PRM black - 1793/69/60 928574
26 4000 2700 OPAL grey yes 1793/69/60 928604
26 4000 2700 PRM grey yes 1793/69/60 928611
26 4000 2700 OPAL white yes 1793/69/60 928642
26 4000 2700 PRM white yes 1793/69/60 928659
26 4000 2700 OPAL black yes 1793/69/60 928680
26 4000 2700 PRM black yes 1793/69/60 928697
26 3000 2558 OPAL grey - 1793/69/60 929205
26 3000 2558 PRM grey - 1793/69/60 929212
26 3000 2558 OPAL white - 1793/69/60 929243
26 3000 2558 PRM white - 1793/69/60 929250
26 3000 2558 OPAL black - 1793/69/60 929281
26 3000 2558 PRM black - 1793/69/60 929298
26 3000 2558 OPAL grey yes 1793/69/60 929328
26 3000 2558 PRM grey yes 1793/69/60 929335
26 3000 2558 OPAL white yes 1793/69/60 929366
26 3000 2558 PRM white yes 1793/69/60 929373
26 3000 2558 OPAL black yes 1793/69/60 929403
26 3000 2558 PRM black yes 1793/69/60 929410
45 4000 4500 OPAL grey - 1793/69/60 928505
45 4000 4500 PRM grey - 1793/69/60 928512
45 4000 4500 OPAL white - 1793/69/60 928543
45 4000 4500 PRM white - 1793/69/60 928550
45 4000 4500 OPAL black - 1793/69/60 928581
45 4000 4500 PRM black - 1793/69/60 928598
45 4000 4500 OPAL grey yes 1793/69/60 928628
45 4000 4500 PRM grey yes 1793/69/60 928635
45 4000 4500 OPAL white yes 1793/69/60 928666
45 4000 4500 PRM white yes 1793/69/60 928673
45 4000 4500 OPAL black yes 1793/69/60 928703
45 4000 4500 PRM black yes 1793/69/60 928710
45 3000 4200 OPAL grey - 1793/69/60 929229
45 3000 4200 PRM grey - 1793/69/60 929236
45 3000 4200 OPAL white - 1793/69/60 929267
45 3000 4200 PRM white - 1793/69/60 929274
45 3000 4200 OPAL black - 1793/69/60 929304
45 3000 4200 PRM black - 1793/69/60 929311
45 3000 4200 OPAL grey yes 1793/69/60 929342
45 3000 4200 PRM grey yes 1793/69/60 929359
45 3000 4200 OPAL white yes 1793/69/60 929380
45 3000 4200 PRM white yes 1793/69/60 929397
45 3000 4200 OPAL black yes 1793/69/60 929427
45 3000 4200 PRM black yes 1793/69/60 929434
593/69/60
9 4000 900 OPAL grey - 593/69/60 928000
9 4000 900 PRM grey - 593/69/60 928017
9 4000 900 OPAL white - 593/69/60 928048
9 4000 900 PRM white - 593/69/60 928055
9 4000 900 OPAL black - 593/69/60 928086
9 4000 900 PRM black - 593/69/60 928093
9 4000 900 OPAL grey yes 593/69/60 928123
9 4000 900 PRM grey yes 593/69/60 928130
9 4000 900 OPAL white yes 593/69/60 928161
9 4000 900 PRM white yes 593/69/60 928178
9 4000 900 OPAL black yes 593/69/60 928208
9 4000 900 PRM black yes 593/69/60 928215
9 3000 850 OPAL grey - 593/69/60 928727
9 3000 850 PRM grey - 593/69/60 928734
9 3000 850 OPAL white - 593/69/60 928765
9 3000 850 PRM white - 593/69/60 928772
9 3000 850 OPAL black - 593/69/60 928802
9 3000 850 PRM black - 593/69/60 928819
9 3000 850 OPAL grey yes 593/69/60 928840
9 3000 850 PRM grey yes 593/69/60 928857
9 3000 850 OPAL white yes 593/69/60 928888
9 3000 850 PRM white yes 593/69/60 928895
9 3000 850 OPAL black yes 593/69/60 928925
9 3000 850 PRM black yes 593/69/60 928932
16 4000 1500 OPAL grey - 593/69/60 928024
16 4000 1500 PRM grey - 593/69/60 928031
16 4000 1500 OPAL white - 593/69/60 928062
16 4000 1500 PRM white - 593/69/60 928079
16 4000 1500 OPAL black - 593/69/60 928109
16 4000 1500 PRM black - 593/69/60 928116
16 4000 1500 OPAL grey yes 593/69/60 928147
16 4000 1500 PRM grey yes 593/69/60 928154
16 4000 1500 OPAL white yes 593/69/60 928185
16 4000 1500 PRM white yes 593/69/60 928192
16 4000 1500 OPAL black yes 593/69/60 928222
16 4000 1500 PRM black yes 593/69/60 928239
16 3000 1400 OPAL grey - 593/69/60 928741
16 3000 1400 PRM grey - 593/69/60 928758
16 3000 1400 OPAL white - 593/69/60 928789
16 3000 1400 PRM white - 593/69/60 928796
16 3000 1400 OPAL black - 593/69/60 928826
16 3000 1400 PRM black - 593/69/60 928833
16 3000 1400 OPAL grey yes 593/69/60 928864
16 3000 1400 PRM grey yes 593/69/60 928871
16 3000 1400 OPAL white yes 593/69/60 928901
16 3000 1400 PRM white yes 593/69/60 928918
16 3000 1400 OPAL black yes 593/69/60 928949
16 3000 1400 PRM black yes 593/69/60 928956
