Specification

High-quality floodlight with inbuilt LED source. The body is made of die-cast aluminum, powder-coated in anthracite grey (RAL 7016), and the mounting bracket is made of black-painted steel. The diffuser is made of 5 mm thick tempered glass. It is equipped with directional lens matrices with 3 different light distributions: symmetrical (120°), asymmetric narrow ASN, and asymmetric wide ASW. Non-corrosive mounting bracket allowing for adjustment angles between -140° to +185°. The luminaire is available in 2 sizes: M and L. Standard equipped with 0.1m long H07RN-F cable and IP66 quick connector.

Wide range of accessories available: protective net, grip for the lighting pole, wall bracket.

Application

The fitting is dedicated to lighting elevations and billboards.

See our luminaires on the BIMobject platform

Options

Rated power of the luminaire [W]	Colour temperature [K]	Luminous flux [lm]	DIMM DALI	Beam angle [°]	Version	Dimensions (H/W/T/S) [mm]	Index
27W
27	3000	3400	-	120	M	321/424/37	698972
27	3000	3400	-	ASN	M	321/424/37	698996
27	3000	3500	-	ASW	M	321/424/37	699016
27	3000	3400	yes	120	M	321/424/37	697371
27	3000	3400	yes	ASN	M	321/424/37	697395
27	3000	3500	yes	ASW	M	321/424/37	697418
27	4000	3600	-	120	M	321/424/37	698965
27	4000	3600	-	ASN	M	321/424/37	698989
27	4000	3750	-	ASW	M	321/424/37	699009
27	4000	3600	yes	120	M	321/424/37	697364
27	4000	3750	yes	ASW	M	321/424/37	697401
41W
41	3000	4900	-	120	M	321/424/37	699030
41	3000	4950	-	ASN	M	321/424/37	699054
41	3000	5150	-	ASW	M	321/424/37	699078
41	3000	4900	yes	120	M	321/424/37	697432
41	3000	4950	yes	ASN	M	321/424/37	697456
41	3000	5150	yes	ASW	M	321/424/37	697470
41	4000	5200	-	120	M	321/424/37	699023
41	4000	5200	-	ASN	M	321/424/37	699047
41	4000	5450	-	ASW	M	321/424/37	699061
41	4000	5200	yes	120	M	321/424/37	697425
41	4000	5200	yes	ASN	M	321/424/37	697449
41	4000	5450	yes	ASW	M	321/424/37	697463
54W
54	3000	6250	-	120	M	321/424/37	699092
54	3000	6300	-	ASN	M	321/424/37	699115
54	3000	6600	-	ASW	M	321/424/37	699139
54	3000	6250	yes	120	M	321/424/37	697494
54	3000	6300	yes	ASN	M	321/424/37	697517
54	3000	6600	yes	ASW	M	321/424/37	697531
54	4000	6650	-	120	M	321/424/37	699085
54	4000	6700	-	ASN	M	321/424/37	699108
54	4000	7000	-	ASW	M	321/424/37	699122
54	4000	6650	yes	120	M	321/424/37	697487
54	4000	6700	yes	ASN	M	321/424/37	697500
54	4000	7000	yes	ASW	M	321/424/37	697524
68W
68	3000	9300	-	120	M	321/424/37	699153
68	3000	9000	-	ASN	M	321/424/37	699177
68	3000	9100	-	ASW	M	321/424/37	699191
68	3000	9300	yes	120	M	321/424/37	697555
68	3000	9000	yes	ASN	M	321/424/37	697579
68	3000	9100	yes	ASW	M	321/424/37	697593
68	4000	9900	-	120	M	321/424/37	699146
68	4000	9559	-	ASN	M	321/424/37	699160
68	4000	9650	-	ASW	M	321/424/37	699184
68	4000	9900	yes	120	M	321/424/37	697548
68	4000	9559	yes	ASN	M	321/424/37	697562
68	4000	9650	yes	ASW	M	321/424/37	697586
79W
79	3000	11350	-	120	L	415/424/37	699337
79	3000	11000	-	ASN	L	415/424/37	699368
79	3000	11100	-	ASW	L	415/424/37	699399
79	3000	11350	yes	120	L	415/424/37	697739
79	3000	11000	yes	ASN	L	415/424/37	697760
79	3000	11100	yes	ASW	L	415/424/37	697791
79	4000	12100	-	120	L	415/424/37	699320
79	4000	11700	-	ASN	L	415/424/37	699351
79	4000	11800	-	ASW	L	415/424/37	699382
79	4000	12100	yes	120	L	415/424/37	697722
79	4000	11700	yes	ASN	L	415/424/37	697753
79	4000	11800	yes	ASW	L	415/424/37	697784
82W
82	3000	11000	-	120	M	321/424/37	699214
82	3000	10600	-	ASN	M	321/424/37	699238
82	3000	10700	-	ASW	M	321/424/37	699252
82	3000	11000	yes	120	M	321/424/37	697616
82	3000	10600	yes	ASN	M	321/424/37	697630
82	3000	10700	yes	ASW	M	321/424/37	697654
82	4000	11700	-	120	M	321/424/37	699207
82	4000	11300	-	ASN	M	321/424/37	699221
82	4000	11400	-	ASW	M	321/424/37	699245
82	4000	11700	yes	120	M	321/424/37	697609
82	4000	11300	yes	ASN	M	321/424/37	697623
82	4000	11400	yes	ASW	M	321/424/37	697647
108W
108	3000	13800	-	120	M	321/424/37	699276
108	3000	13350	-	ASN	M	321/424/37	699290
108	3000	13500	-	ASW	M	321/424/37	699313
108	3000	13800	yes	120	M	321/424/37	697678
108	3000	13350	yes	ASN	M	321/424/37	697692
108	3000	13500	yes	ASW	M	321/424/37	697715
108	4000	14700	-	120	M	321/424/37	699269
108	4000	14200	-	ASN	M	321/424/37	699283
108	4000	14400	-	ASW	M	321/424/37	699306
108	4000	14700	yes	120	M	321/424/37	697661
108	4000	14200	yes	ASN	M	321/424/37	697685
108	4000	14400	yes	ASW	M	321/424/37	697708
109W
109	3000	14950	-	120	L	415/424/37	699429
109	3000	14500	-	ASN	L	415/424/37	699450
109	3000	14700	-	ASW	L	415/424/37	699481
109	3000	14950	yes	120	L	415/424/37	697821
109	3000	14500	yes	ASN	L	415/424/37	697852
109	3000	14700	yes	ASW	L	415/424/37	697883
109	4000	15900	-	120	L	415/424/37	699412
109	4000	15400	-	ASN	L	415/424/37	699443
109	4000	15600	-	ASW	L	415/424/37	699474
109	4000	15900	yes	120	L	415/424/37	697814
109	4000	15400	yes	ASN	L	415/424/37	697845
109	4000	15600	yes	ASW	L	415/424/37	697876
122W
122	3000	15500	yes	120	M	321/424/37	741005
122	3000	14850	yes	ASN	M	321/424/37	741029
122	3000	15200	yes	ASW	M	321/424/37	741043
122	3000	15500	-	120	M	321/424/37	697258
122	3000	14850	-	ASN	M	321/424/37	697272
122	3000	15200	-	ASW	M	321/424/37	697296
122	4000	16500	yes	120	M	321/424/37	741012
122	4000	15800	yes	ASN	M	321/424/37	741036
122	4000	16200	yes	ASW	M	321/424/37	741050
122	4000	16500	-	120	M	321/424/37	697241
122	4000	15800	-	ASN	M	321/424/37	697265
122	4000	16200	-	ASW	M	321/424/37	697289
145W
145	3000	18850	-	120	L	415/424/37	699511
145	3000	18300	-	ASN	L	415/424/37	699542
145	3000	18500	-	ASW	L	415/424/37	699573
145	3000	18850	yes	120	L	415/424/37	697913
145	3000	18300	yes	ASN	L	415/424/37	697944
145	3000	18500	yes	ASW	L	415/424/37	697975
145	4000	20100	-	120	L	415/424/37	699504
145	4000	19500	-	ASN	L	415/424/37	699535
145	4000	19700	-	ASW	L	415/424/37	699566
145	4000	20100	yes	120	L	415/424/37	697906
145	4000	19500	yes	ASN	L	415/424/37	697937
145	4000	19700	yes	ASW	L	415/424/37	697968
182W
182	3000	22130	-	120	L	415/424/37	696015
182	3000	21500	-	ASN	L	415/424/37	696053
182	3000	21750	-	ASW	L	415/424/37	696039
182	4000	23550	-	120	L	415/424/37	697067
182	4000	22900	-	ASN	L	415/424/37	697081
182	4000	23150	-	ASW	L	415/424/37	697104
182	5700	28400	-	120	L	415/424/37	697074
182	5700	27600	-	ASN	L	415/424/37	697098
182	5700	27900	-	ASW	L	415/424/37	697111
184W
184	3000	21000	-	120	M	321/424/37	696008
184	4000	22350	-	120	M	321/424/37	697302
184	5700	23150	-	120	M	321/424/37	697319
210W
210	3000	24700	-	ASW	L	415/424/37	696046
210	3000	25100	-	120	L	415/424/37	696022
210	3000	24450	-	ASN	L	415/424/37	696060
210	4000	26050	-	ASN	L	415/424/37	699801
210	4000	26300	-	ASW	L	415/424/37	699818
210	4000	26800	-	120	L	415/424/37	699825
210	5700	27400	-	ASN	L	415/424/37	697197
210	5700	27700	-	ASW	L	415/424/37	697203
210	5700	28200	-	120	L	415/424/37	697210
243W
243	3000	28050	-	120	L	415/424/37	696077
243	4000	29850	-	120	L	415/424/37	697135
243	5700	30900	-	120	L	415/424/37	697142

Show more Show less

Accessories

Hide accessories

Index	Accessory name
699993	QUEST 2 LED M - recessed frame
699986	QUEST 2 LED L - recessed frame
699962	QUEST 2 LED L protective grid RAL7016
699979	QUEST 2 LED M protective grid RAL7016
567728	QUEST 2 LED M/L Pole holder
965913	QUEST 2 LED M/L MAX wall mount RAL7016
559938	QUEST PLUS LED M/L wall holder RAL9006

QUEST 2 LED M - recessed frame (699993)

QUEST 2 LED L - recessed frame (699986)

QUEST 2 LED L protective grid RAL7016 (699962)

QUEST 2 LED M protective grid RAL7016 (699979)

QUEST 2 LED M/L Pole holder (567728)

QUEST 2 LED M/L MAX wall mount RAL7016 (965913)

QUEST PLUS LED M/L wall holder RAL9006 (559938)
