Quest 2 LED Endura HB

Downloads

Specification

High-quality highbay with inbuilt LED source. The body is made of die-cast aluminium, powder-coated in anthracite grey (RAL 7016), and the mounting bracket is made of black-painted steel. The diffuser is made of 5 mm thick tempered glass.

Application

Quest 2 LED Endura is a fitting designed for lighting surfaces with an ambient temperature up to +60°C (eg. for industrial plants or bakeries). The unfavorable conditions of the environment do not have an influence on the fitting’s reliability and efficacy. In rooms such as cold stores, the requirements for lighting are far from standard. Only the fittings especially suited for working in such conditions can be used in rooms with cold temperatures is a fitting designed for lighting surfaces with the temperature down to -35°C.

Options

Rated power of the luminaire [W]	Colour temperature [K]	Luminous flux [lm]	Beam angle [°]	DIMM DALI	Version	Mounting version	Dimensions [mm]	Index
surface
108	4000	14700	120	yes	1xM	surface	321/424/37	696527
108	4000	14700	120	-	1xM	surface	321/424/37	698842
145	4000	20100	120	yes	1xL	surface	415/424/37	696589
145	4000	20100	120	-	1xL	surface	415/424/37	698903
216	4000	29400	120	yes	2xM	surface	671/424/37	696534
216	4000	29400	120	-	2xM	surface	671/424/37	698859
290	4000	40200	120	yes	2xL	surface	859/424/37	696596
290	4000	40200	120	-	2xL	surface	859/424/37	698910
suspended
108	4000	14700	120	yes	1xM	suspended	321/424/37	696404
108	4000	14700	120	-	1xM	suspended	321/424/37	698729
145	4000	20100	120	yes	1xL	suspended	415/424/37	696466
145	4000	20100	120	-	1xL	suspended	415/424/37	698781
216	4000	29400	120	yes	2xM	suspended	671/424/37	696411
216	4000	29400	120	-	2xM	suspended	671/424/37	698736
290	4000	40200	120	yes	2xL	suspended	859/424/37	696473
290	4000	40200	120	-	2xL	suspended	859/424/37	698798

Accessories

Hide accessories

Index	Accessory name
559907	QUEST PLUS LED M protective grid RAL9006
559914	QUEST PLUS LED L protective grid RAL9006
559952	QUEST PLUS LED HB M protective grid RAL9006 single suspension
559945	QUEST PLUS LED HB L protective grid RAL9006 single suspension
699993	QUEST 2 LED M - recessed frame
699986	QUEST 2 LED L - recessed frame

QUEST PLUS LED M protective grid RAL9006 (559907)

QUEST PLUS LED L protective grid RAL9006 (559914)

QUEST PLUS LED HB M protective grid RAL9006 single suspension (559952)

QUEST PLUS LED HB L protective grid RAL9006 single suspension (559945)

QUEST 2 LED M - recessed frame (699993)

QUEST 2 LED L - recessed frame (699986)
