Linero LED

Name: Lenalighting
Address: ul. Kórnicka 52, Środa Wielkopolska, Wielkopolskie, 63-000, Polska
Telephone: 61 28 60 300

Light source	LED
Colour temperature	4000K
Diffuser type	lens matrix
Mounting version	surface suspended
Dimensions [mm]	620/61/129
Application	industrial

LED220-240vIIik09ip66CEQuick installation

Ask about this product

Options

Linero LED

Ask about this product

Options

Light source	LED
Colour temperature	4000K
Diffuser type	lens matrix
Mounting version	surface suspended
Application	industrial

Downloads

Download All

Specification

A range of lightweight, hermetically sealed High-Bay linear luminaires, made from extruded aluminium, featuring a heat sink to dissipate excess heat and an outdoor on/off power supply (an optional 1–10 V dimming function is available for each version). It combines the characteristics of durability and weatherproofing with the highest luminous efficacy. Its uncompromising, modern design represents a breakthrough in the design of efficient yet economical industrial luminaires. Professional optics made from durable polycarbonate (PC) offer great flexibility in selecting the optimal solution, even at significant installation heights.

Application

Designed for the most demanding production and warehouse environments, where the highest quality and quantity of light at the lowest possible investment cost are the priority.

Options

Rated power of the luminaire [W]	Colour temperature [K]	Luminous flux [lm]	Light distribution type	Luminous efficacy [lm/W]	Dimensions (H/W/T/S) [mm]	Index
71	4000	10800	CW	152	620/61/129	278990
71	4000	11000	SN	155	620/61/129	488313
71	4000	11000	VN	155	620/61/129	488252
71	4000	11000	MW	155	620/61/129	488054
71	4000	11000	CN	155	620/61/129	488375
71	4000	11000	VW	155	620/61/129	488191
71	4000	11000	SW	155	620/61/129	488139
86	4000	12700	CW	148	620/61/129	278983
86	4000	12950	SN	151	620/61/129	488306
86	4000	12950	VN	151	620/61/129	488245
86	4000	12950	CN	151	620/61/129	488368
86	4000	12950	VW	151	620/61/129	488184
86	4000	12950	MW	151	620/61/129	488047
86	4000	12950	SW	151	620/61/129	488122
99	4000	14200	CW	143	620/61/129	278976
99	4000	14450	SW	146	620/61/129	488115
99	4000	14450	SN	146	620/61/129	488290
99	4000	14450	VW	146	620/61/129	488177
99	4000	14450	VN	146	620/61/129	488238
99	4000	14450	MW	146	620/61/129	488030
99	4000	14450	CN	146	620/61/129	488351
111	4000	15350	CW	138	620/61/129	278969
111	4000	15650	VN	141	620/61/129	488221
111	4000	15650	SN	141	620/61/129	488283
111	4000	15650	CN	141	620/61/129	488344
111	4000	15650	MW	141	620/61/129	488023
111	4000	15650	SW	141	620/61/129	488108
111	4000	15650	VW	141	620/61/129	488160
123	4000	16550	CW	135	620/61/129	278952
123	4000	16850	MW	137	620/61/129	488016
123	4000	16850	CN	137	620/61/129	488337
123	4000	16850	SN	137	620/61/129	488276
123	4000	16850	VN	137	620/61/129	488214
123	4000	16850	VW	137	620/61/129	488153
123	4000	16850	SW	137	620/61/129	488092
139	4000	18300	CW	132	620/61/129	278945
139	4000	18650	CN	134	620/61/129	488320
139	4000	18650	SN	134	620/61/129	488269
139	4000	18650	VN	134	620/61/129	488207
139	4000	18650	VW	134	620/61/129	488146
139	4000	18650	SW	134	620/61/129	488085
139	4000	18650	MW	134	620/61/129	488009

Show more ↓ Show less ↑
